Parts and Functions

Front

No.	Name	Function
1	Stacker	Stacks up the ejected documents. It can be kept at an optimum height to straighten the documents.
2	Stacker side guide	Aligns the documents in width direction as they are ejected onto the stacker.
3	Stacker extension	Pull out and adjust to the length of the documents.
4	Paper stop	Guides the ejected documents in the length direction to prevent them from being scattered. Though documents can be aligned without the paper stop, it can be used to stack them more neatly.
5	Hopper side guide	Guides the documents in the width direction as they are fed into the scanner.
6	Hopper extension	Pull out to place long documents on the hopper.
7	Hopper	A table for loading documents to scan.
8	Paper output	Ejects the scanned documents.
9	Top cover	A cover for the upper paper path. Open it to remove jammed documents or clean the inside of the scanner.
10	Top cover release tab	Push up to open the top cover.
11	Operator panel	It consists of an LCD, buttons and check LED. It can be used to operate the scanner or check its status. For more details about the operator panel, refer to How to Use the Operator Panel.
12	Power button	Turns the power ON/OFF.
13	ADF release tab	Push up to open the ADF.
14	ADF (Automatic Document Feeder)	Pulls and feeds the documents loaded on the hopper one at a time. Open this to replace consumables or to clean the inside of the scanner.

No.	Name	Function
1	Ventilation port	An outlet for ventilating hot air from inside the scanner.
2	Power connector	A connector for the power cable.
3	Main power switch	Powers ON/OFF the scanner.
4	USB connector	For connecting a USB cable.

No.	Name	Function
1	Pick roller	A set of rollers which separates one sheet off the documents loaded in the hopper, and feeds the document into the ADF. For information on how to remove the pick rollers, refer to Replacing the Pick Roller.
2	Separator roller	A set of rollers which separates one sheet off the documents loaded in the hopper, and feeds the document into the ADF. For information on how to remove the separator roller, refer to Replacing the Separator Roller.
3	Brake roller	A roller that prevents more than one sheet of documents to be fed into the ADF at once. For details about removing the brake roller, refer to Replacing the Brake Roller.

No.

Name

Function

1

Pick roller

A set of rollers which separates one sheet off the documents loaded in the hopper, and feeds the document into the ADF.

For information on how to remove the pick rollers, refer to Replacing the Pick Roller.

2

Separator roller

A set of rollers which separates one sheet off the documents loaded in the hopper, and feeds the document into the ADF.

For information on how to remove the separator roller, refer to Replacing the Separator Roller.

3

Brake roller

A roller that prevents more than one sheet of documents to be fed into the ADF at once.

For details about removing the brake roller, refer to Replacing the Brake Roller.
