Multifeed

Specify a method for multifeed detection. Detect by monitoring overlapping, document length, or a combination of both.

It can also be configured from the scanner driver's setup dialog box. Note that priority is given to the scanner driver setting.

None / Check Overlapping (Ultrasonic) / Check Length / Check Overlapping and Length

Length (when detecting from the length difference, select from 10/15/20 mm)

Multifeed detection when scanning in manual feeding mode

Specify this item to enable multifeed detection during manual feeding.

Disable / Follow driver settings

Page Edge Filler (ADF)

Specify a width for the margin off the edge of the scanned image to fill in black or white.

The margins are filled in white when the background is white, and filled in black when the background is black.

It can also be configured from the scanner driver's setup dialog box. Note that priority is given to the setting with a larger value.

Top/Left/Right: 0 to 15 mm

Bottom: -7 to 7 mm (in increments of 1 mm)

(A: Image, B: Filled area, A+B: Output)

Dropout color

Select a color to be dropped out from the scanned image (black & white/grayscale only).

It can also be configured from the scanner driver's setup dialog box. Note that priority is given to the scanner driver setting.

Red / Green / Blue / None

Pre-Pick

Select [Yes] to prioritize the processing speed and [No] for otherwise.

It can also be configured from the scanner driver's setup dialog box. Note that priority is given to the scanner driver setting.

Yes / No

Page Edge Filler (Automatic Page Size Detection)

Specify the range of area to fill in when [Automatic Page Size Detection] is selected.

Specify a width for the margin off the edge of the scanned image to fill in black or white.

The margins are filled in white when the background is white, and filled in black when the background is black.

It can also be configured from the scanner driver's setup dialog box. Note that priority is given to the setting with a larger value.

Top/Bottom/Left /Right: 0 to 7.5 mm

(in increments of 0.5 mm)

(A: Image, B: Filled area, A+B: Output)

Document check area specification for Multifeed Detection

Selected range: Select this item to restrict the area to run multifeed detection on.

[Selected range] check box

Enable/Disable (Left/Middle/Right): Specify whether to enable or disable multifeed detection for the specified area.

Enable / Disable

(when [Selected range] is selected)

Start: Specify the start point of the check area in length (mm) from the top edge of the document.

0 to 510 mm (in increments of 2 mm)

End: Specify the end point of the check area in length (mm) from the top edge of the document.

0 to 510 mm (in increments of 2 mm)

Intelligent Multifeed Function

When there is paper of the same size attached to a designated location on the page, configure the scanner to memorize the location of the attachment and not detect multifeeds for that location.

Note that you first need to select [Check Overlapping (Ultrasonic)] for the multifeed detection setting in Specifying a Multifeed Detection Method [Multifeed] or the scanner driver's setup dialog box.

It can also be configured from the operator panel.

Manual mode / Auto mode 1 / Auto mode 2

Select to clear the overlap pattern (length, location) memorized in Auto mode.

[Clear overlap pattern] check box

Select to enable the function for memorizing an overlap pattern when overlapped documents are detected in Auto mode.

Note that you first need to select [Stop and Show Image] for [Multifeed Detection] in the scanner driver's setup dialog box.

[Memorize the overlap pattern automatically] check box

Specify whether or not to memorize the overlap pattern upon power-off.

Remember / Do not remember

Number of paper feeding retries

Configure this setting to change the number of feeding retries upon pick errors.

It can also be configured from the operator panel.

1 to 12 times

Retain current paper thickness

Specify whether or not to memorize the paper separation force setting of the operator panel upon turning the power off.

Remember / Do not remember

Cleaning Cycle

Specify the cycle for cleaning the scanner.

Also specify whether or not to show a message for cleaning from the scanner driver.

1,000 to 255,000 sheets

(in increments of 1,000)

[Show cleaning instructions.] check box

Life Counter Alarm Setting

Specify the replacement cycles for the consumables.

Each consumable

10,000 to 2,550,000 sheets

(in increments of 10,000)

Set the interval for feeding sheets

If the bottom of the scanned image is partially missing due to a large skew when scanning in Automatic Page Size Detection, specify a longer interval to feed the documents.

Specifying a longer interval leaves more time between each document to be scanned.

Short (default) - Long

(1 to 4 levels)

Pick Speed

When multifeeds or paper jams occur frequently, the symptom may be improved by slowing down the speed (pick speed) in which the documents are fed.

It can also be configured from the operator panel.

Normal / Slower

Soft Pick Setting

When you experience pick errors from the separator roller slipping on the paper, or paper jams from scanning thin papers of small widths, the symptom may be improved by bringing down the pick roller unit and keeping the unit at the lower position (disabling the Soft Pick Setting).

It can also be configured from the operator panel.

Enable / Disable

AutoCrop Boundary

Specify whether or not to optimize (round up/down) the fractional part of the scanned image data.

Normal / Optimize

Auto color Detection

Specify the slice level for Auto Color Detection.

1 to 255 levels

Alarm setting

Specify whether or not to sound an alarm when an error such as multifeed or paper jam occurs.

It can also be configured from the operator panel.

Disable alarm / Low volume alarm / High volume alarm

Jam Detection outside of scannable area when transporting paper

Specify whether or not to judge the symptom as paper jam when a document is skewed and passes outside the supported scanning area.

Enable / Disable

Imprinter selection

Specify which imprinter to use when both the Front-Side Imprinter and Back-Side Imprinter are installed.

It can also be configured from the scanner driver's setup dialog box. When [Normal (obey Host specification)] is selected, priority is given to the scanner driver settings. When [Forcibly select Front-Side Imprinter] or [Forcibly select Back-Side Imprinter] is selected, priority is given to the Software Operation Panel settings.

Normal (obey Host specification) /Forcibly select Front-Side Imprinter /Forcibly select Back-Side Imprinter (when the imprinter option is installed)

Timeout for manual feeding

Specify the waiting time to cancel manual feeding.

It can also be configured from the operator panel.

5, 10, 20, 30, 40, 50, 60, 70, 80, 90, 100, 110, 120, 180, 240, 300, 360, 420, 480, 540, 600, 900, 1200, 1500, 1800, 1999 (seconds)

Paper Protection

Specify whether to enable or disable Paper Protection. Enabling this setting reduces the risk of having your documents damaged in such ways, by stopping the scan when the scanner detects a document that is unusually warped.

Paper Protection is disabled in Manual Feed mode.

It can also be configured from the scanner driver's setup dialog box or the operator panel. Note that priority is given to the scanner driver setting unless you have prioritized the operator panel setting.

Enable / Disable

Paper Protection Sensitivity

Sensitivity Setting: you can specify the sensitivity to detect an abnormal feeding of documents when Paper Protection is enabled.

It can also be configured from the operator panel. Note that you can prioritize the operator panel setting.

Low / Normal / High

Detection Range: you can specify the range to detect an abnormal feeding of documents when Paper Protection is enabled.

Normal / Large

Scan Setting for Document with Tab (Automatic Page Size Detection)

For documents with index tabs or index stickers attached on the bottom of the page, you can keep the tab (index or index stickers) on the scanned image when scanning in Automatic Page Size Detection. Specifying [Document with tab] shows the image of the tab, but slows down the scanning speed.

Document with tab / Document without tab / Non-rectangular document

Maintenance and Inspection Cycle

Specify the cycle for scanner maintenance and inspection to be performed by a service engineer.

When the specified time period elapses since the last periodical maintenance and inspection, a message for periodical maintenance appears.

Disable / Enable

Maintenance/Inspection cycle: 1 to 12 months

Overscan Control

Outputs the image in the optimum position when the image is partially missing due to a large skew.

Normal / Optimize

Black frame thickness:

Thin (Default) to Thick (level 1 to 3)

Low-speed Feed Mode

Select whether to perform a slow scanning speed, in order to protect the documents.

It can also be configured from the operator panel.

Disable / Enable

Automatic Separation Control

Select whether to control the paper separation force automatically for each document type.

It can also be configured from the operator panel.

Disable / Enable
