How to Load a Document in the ADF Paper Chute (Feeder)

  1. Pull out the chute extensions according to the length of the document.

    For details, refer to Setting Up the ADF Paper Chute (Feeder).

  2. Adjust the stacker according to the length of the documents.

    For details, refer to Setting Up the Stacker [fi-8190/fi-8170/fi-8150/fi-8150U] or Setting Up the Stacker [fi-8290/fi-8270/fi-8250/fi-8250U].

  3. Load a document in the ADF paper chute (feeder).

    Load the document face-down in the ADF paper chute (feeder).

    Loading a Document
    ATTENTION

    • Remove all paper clips and staples.

    • Reduce the number of documents when documents are not fed into the scanner or overlapped documents are fed.

  4. Adjust the side guides to the width of the documents.

    Move the side guides so that there is no space between the side guides and the documents.

    When there is a space between the side guides and the documents, the documents may be fed skewed.

    Adjusting the Side Guides
ATTENTION

When you scan long pages, take note of the following:

  • When loading a document

    Support the loaded document with your hand so it does not fall out of the ADF paper chute (feeder).

    Holding the Document Down

  • When the document is ejected

    Secure enough space around the stacker and catch the ejected sheet so that it does not fall off the stacker.

    Catching a Document

Be careful not to cut your finger on the edge of the document.
